• Latest addition to the HSD lineup, ideal for tackling hills
• Powerful Bosch® Performance Line motor for up to 65 Nm of torque
• 500 Wh battery for a range of up to 118 km (74 mi)
• Custom Suntour suspension fork
• 9-speed Shimano® Alivio Shadow derailleur
• Shimano hydraulic disc brakes
• Abus® keyed-alike frame lock
• Fits riders from 150 to 195 cm (4’11” – 6’5”)
• Fits one Thule® Yepp Maxi, Yepp Nexxt Maxi, or Bobike® GO Maxi child seat—no adapters needed

SPECIFICATIONS GENERAL INFO

SPEEDS:1 x 9

WEIGHT:25.7 kg (56.7 lb)

GEAR INCHES:33" - 97" (2.65 - 7.72 m)

FOLDING SIZE:163 × 40.5 × 86 cm (64.2 × 15.9 × 33.9 in)

FOLDING TIME:5 sec

FRAME SIZES:One size

DISTANCE: SEATPOST TO HANDLEBAR:49 - 59 cm (19.3 - 23.2 in)

DISTANCE: SADDLE TO PEDAL:69 - 105 cm (27.2 - 41.3 in)

SUGGESTED RIDER HEIGHT:150 - 195 cm (59.1 - 76.8 in)

MAX GROSS VEHICLE WEIGHT:170 kg (374.8 lb)

MAX RIDER WEIGHT:120 kg (264.6 lb)

FRAME:Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 170 kg

FORK:Suntour custom for Tern, Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 170 kg

COCKPITHANDLEPOST:Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 290 mm

STEM:Tern Andros, adjustable, forged construction, patented technology

HEADSET:Tern Flux by FSA, cartridge bearings, Physis integrated

HANDLEBAR:Tern Sweep, 6061-AL, Tern Andros adapted

GRIPS/BAR TAPE:Ergon

SADDLE:Tern Upright by Velo

SEATPOST:Tern Telescope, 34.9/30.9 mm, 2014-

ALSEATPOST CLAMP:Tern Collar

BRAKESFRONT BRAKE:Shimano, hydraulic disc, 180 mm rotor

REAR BRAKE:Shimano, hydraulic disc, 160 mm rotor

BRAKE LEVERS:Shimano, hydraulic disc

BRAKE CABLE & HOUSING:Shimano, hydraulic disc

WHEELSFRONT WHEEL:Tern Atlas H, cargo wheel

REAR WHEEL:Tern Atlas H, cargo wheel

FRONT HUB:Novatec, Thru-axle, sealed bearings

REAR HUB:Shimano disc

SPOKES AND NIPPLES:Stainless steel

RIMS:Tern Atlas H, wide 35 mm

TIRES:Schwalbe Big Apple, 55-406, puncture protection, Reflex

TRANSMISSIONSHIFTER(S):Shimano Alivio, 1 x 9 spd, trigger

FRONT DERAILLEUR:n/a

REAR DERAILLEUR:Shimano Alivio Shadow

CRANKSET:Tern HSD custom

CASSETTE/FREEWHEEL:Shimano 11-32T, 9 spd

BOTTOM BRACKET:Motor integrated

CHAIN:9 spd, DHT for eBike, GST corrosion resistant coating

PEDALS:Urban with non-slip surface

SHIFTER CABLE & HOUSING:Jagwire LEX-SL, slick treatment, alloy ferrules

E-SYSTEMMOTOR:Bosch Performance, 300% Assist, 65 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)

*Note: These are our standard model specifications. The bike's weight and folded dimension may not include racks and fenders. The specifications for your country may differ slightly. We do our best to ensure that the specifications listed here accurately reflect the exact parts found on our production bikes. However, component changes do occur for various reasons and there may be brief delays on site updates. We reserve the right to make component changes without prior notification, which may cause discrepancies with the information listed on the web.
